LS10-26B05R3
10 W on-board AC/DC converter module, 5 VDC output
MORNSUN
On-board AC/DC Power Modules
LS10-26BxxR3 series
MORNSUN LS10-26B05R3: 85-528 VAC / 100-745 VDC input, 5 VDC / 2000mA regulated output, 4000VAC isolation, 38.00 x 20.00 x 15.25 mm. Specifications below are taken from the current official datasheet; price and lead time are quoted on request.
- Output power
- 10 W
- Input
- 85-528 VAC / 100-745 VDC
- Output
- 5 VDC
- Output current
- 2 A (2000 mA)
- Isolation
- 4000VAC
- Package
- SIP
Price and lead time are quoted manually. Send the quantity and the destination and we will confirm what is possible for this part. Availability, shipping and order acceptance are subject to confirmation.
Samples may be available for selected models. Volume pricing is available. Price, MOQ, lead time and shipping eligibility are confirmed by quotation.
Specifications
| Power(W) | 10 |
|---|---|
| Vin(VAC) | 85-528 |
| Vin(VDC) | 100-745 |
| Vout(VDC) | 5 |
| Iout | 2000mA |
| No. of Outputs | 1 |
| Isolation | 4000VAC |
| Package | SIP |
| Dimension(mm) | 38.00*20.00*15.25 |
Features
- Ultra-wide 85-528 VAC / 100-745 VDC input range
- Can be connected across any two phases
- Accepts AC or DC on the same input terminals
- Operating ambient temperature -40 °C to +85 °C
- High I/O isolation test voltage up to 4000 VAC
- Output short-circuit and over-current protection
- SIP package, 38.00 × 20.00 × 15.25 mm
Standards shown are the design references printed on the current datasheet. Ask us to confirm the certificate status that applies to your shipment.
Typical applications
- Three-phase industrial equipment
- Switchgear and protection relays
- Electric power and smart grid devices
- Instrumentation on unstable supplies
About this module
The LS10-26BxxR3 series does the same 10 W job as the LS10-13B, but survives a far higher line voltage: 85-528 VAC, which means it can sit across any two phases of a three-phase supply and ride out the kind of line excursions that destroy an ordinary 305 VAC-rated module.
That makes it the part to specify for equipment installed on industrial networks, in switchgear and in electric-power applications where the supply is not guaranteed to behave. Isolation test voltage is 4000 VAC.
Brand, manufacturer and supply
- Brand
- MORNSUN
- Manufacturer
- MORNSUN Guangzhou Science & Technology Co., Ltd.
- Technical support
- MORNSUN Guangzhou Science & Technology Co., Ltd.
- Supplied by
- Raitop Information Technology Co., Ltd.
Related reading
Where this data comes from
| Item | Source (manufacturer official) | Version | Checked |
|---|---|---|---|
| datasheet, verified parameters | https://www.mornsun-power.com/public/uploads/pdf/LS10-26BxxR3.pdf | 2022.12.23-A/2 | 2026-09-16 |
| product image | https://www.mornsun-power.com/public/uploads/productsImg/LS10-26BxxR3.jpg | — | 2026-09-16 |
| specification table, features | https://www.mornsun-power.com/html/products-detail/LS10-26BxxR3.html | — | 2026-09-16 |
Raitop is an independent supplier. Product images, datasheets and specifications are MORNSUN material reproduced with permission.
