LS05-26B09R3
5 W AC/DC converter module, 9 V output, SIP package
The LS05-26B09R3 is a 5 W AC/DC converter module with an input of 90-528 VAC or 100-745 VDC and a 9 VDC output rated 560mA. Isolation is 4000VAC, the package is SIP, and it measures 33.50*17.20*13.00 mm. Every figure above comes from the manufacturer's current official product data; Raitop quotes this part on request.
- Input
- 90-528 VAC
- Output
- 9 VDC
- Output current
- 560 mA
- Isolation
- 4000VAC
- Package
- SIP
Price and lead time are quoted manually. Send the quantity and the destination and we will confirm what is possible for this part. Availability, shipping and order acceptance are subject to confirmation.
Samples may be available for selected models. Volume pricing is available. Price, MOQ, lead time and shipping eligibility are confirmed by quotation.
Specifications
| Power(W) | 5 |
|---|---|
| Vin(VAC) | 90-528 |
| Vin(VDC) | 100-745 |
| Vout(VDC) | 9 |
| Iout | 560mA |
| No. of Outputs | 1 |
| Isolation | 4000VAC |
| Package | SIP |
| Dimension(mm) | 33.50*17.20*13.00 |
Brand, manufacturer and supply
- Brand
- MORNSUN
- Manufacturer
- MORNSUN Guangzhou Science & Technology Co., Ltd.
- Technical support
- MORNSUN Guangzhou Science & Technology Co., Ltd.
- Supplied by
- Raitop Information Technology Co., Ltd.
Where this data comes from
| Item | Source (manufacturer official) | Version | Checked |
|---|---|---|---|
| specs_json | https://www.mornsun-power.com/index/sitesearch/partlink/keyword/LS05-26B09R3.html | — | 2026-09-17 |
| image_path | https://www.mornsun-power.com/public/uploads/productsImg/120/LS05-26BxxR3.jpg | — | 2026-09-17 |
| datasheet_source_url | https://www.mornsun-power.com/html/pdf/LS05-26B09R3.html | — | 2026-09-17 |
Raitop is an independent supplier. Product images, datasheets and specifications are MORNSUN material reproduced with permission.
